Responsibility is quality assurance,quality is the life of the brand.
 |
| Place of Origin: | Chongqing,China |
| Brand Name: | HLA |
| Certification: | ISO9001,CE |
| Model Number: | DVP30-200 |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | $2000~$20000 |
| Packaging Details: | Wooden case |
| Delivery Time: | 10 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 sets |
| Flow: | 1800 L/h-18000L/h | Impurity Size: | ≤1μm |
|---|---|---|---|
| Filter Elements: | Three Stages | Countrol: | PLC Fully Automatic |
| Gas Content: | ≤0.1% | Heating Method: | Electric Heating |
| Cleanness: | ≤ Grade 6 (NAS) | Temperature Range: | 0-80°C |
| Highlight: | PLC Transformer Oil Filter Machine,Fully Automatic Transformer Oil Filter Machine,Three Stages Transformer Oil Filter Machine |
||
The Transformer Oil Filtration Machine is equipped with a PLC fully automatic control system that makes it easy to operate. The automatic control system ensures that the filtration process is carried out smoothly and efficiently. The system is designed to monitor the filtration process and adjust the parameters accordingly. This ensures that the transformer oil is purified to the desired level.
The Transformer Oil Filtration Machine is designed for Transformer Oil Dehydration and Transformer oil treatment. The double-stage filtration system removes impurities from the transformer oil, thereby improving its dielectric strength. This helps in extending the life of the transformer and reducing the frequency of maintenance and repairs.
The Transformer Oil Filtration Machine comes with several optional items that can be included to enhance its performance. One such item is the online moisture tester. This device helps in monitoring the moisture content of the transformer oil during the filtration process. This ensures that the oil is properly dehydrated, which improves its dielectric strength.
Another optional item that can be included in the Transformer Oil Filtration Machine is the flowmeter. This device helps in monitoring the flow rate of the transformer oil during the filtration process. This ensures that the oil is filtered at a consistent rate, which helps in improving the efficiency of the filtration process.
In conclusion, the Transformer Oil Filtration Machine is an essential component in the transformer oil purifier plant. It is a double-stage filtration system that helps in removing impurities from transformer oil. The machine is equipped with a PLC fully automatic control system that makes it easy to operate. It is suitable for use in different environmental conditions and comes with several optional items that can be included to enhance its performance.
The transformer oil purification plant is designed to remove moisture, gas, and impurities from transformer oil, thus improving the insulation and dielectric strength of the oil. This equipment is perfect for industries that use transformers such as power plants, substations, and transformer manufacturing companies.
The Transformer Oil Filtration Machine is also ideal for transformer oil recycling. The equipment can remove impurities from used transformer oil, thus extending the life cycle of the transformer oil, reducing waste, and saving costs. The oil filtration plant is highly efficient and can purify large volumes of oil in a short amount of time.
The Transformer Oil Filtration Machine is suitable for a variety of insulating oil purification applications, including insulating oils for transformers, circuit breakers, and switchgear. The equipment is easy to operate and maintain, making it ideal for both small and large-scale operations.
Other optional items that can be added to the Transformer Oil Filtration Machine include an online moisture tester and a flowmeter. These additional features enable users to monitor the oil purification process and ensure that the oil meets the required standards.
In summary, HLA DVP30-200 Transformer Oil Filtration Machine is a reliable and efficient equipment for transformer oil purification and recycling. Its high-performance features and optional items make it suitable for a variety of insulating oil purification applications. With this equipment, users can achieve clean transformer oil that meets the required standards.
Equipment parameters:
| Model | DVP30 | DVP50 | DVP80 | DVP100 | DVP125 | DVP150 | DVP200 | DVP250 | DVP300 | |||
| Capacity(L/min) | 30 | 50 | 80 | 100 | 125 | 150 | 200 | 250 | 300 | |||
| Vacuum level | -0.06~-0.095 Mpa | |||||||||||
| Working pressure | ≤ 0.4 Mpa | |||||||||||
| Ultimate vacuum | ≤ 5 Pa | |||||||||||
| Temperature range | 20-80℃ | |||||||||||
| Filtering precision | ≤1 micron | |||||||||||
| Continuous work | ≥200 hr | |||||||||||
| No failure running | ≥5000 hr | |||||||||||
| Power supply | 380V, 50HZ, 3PH ( or Customized ) | |||||||||||
| Working noise | 65 dB | |||||||||||
| Heating power (kw) | 24 | 30 | 48 | 60 | 72 | 90 | 125 | 136 | 150 | |||
| Total power (kw) | 27 | 34 | 54 | 68 | 80 | 100 | 135 | 148 | 165 | |||
| Inlet/outlet(mm) | 32 | 32 | 44 | 44 | 48 | 50 | 55 | 60 | 65 | |||
| Weight (kg) | 300 | 400 | 500 | 600 | 700 | 800 | 1000 | 1150 | 1300 | |||
|
Dimension (mm) |
L | 1300 | 1350 | 1500 | 1800 | 1900 | 2000 | 2100 | 2150 | 2300 | ||
| W | 1000 | 1000 | 1100 | 1150 | 1200 | 1250 | 1300 | 1350 | 1400 | |||
| H | 1500 | 1500 | 1600 | 2000 | 2100 | 2150 | 2200 | 2250 | 2300 | |||
Index Of Purified Oil:
| Breakdown voltage | ≥ 70KV |
| Water content | ≤ 3ppm |
| Gas content | ≤0.1% |
| Filtering particles | ≥99.5% |
| Particles size | ≤ 1 micron |
| Cleanness | ≤ Grade 6 (NAS) |
| Processing by regeneration device as following (Optional device) | |
| Acid value | ≤ 0.03 mgKOH/g |
| Water-solubility | ≥ 5.4 PH |
| Flash point (close cup) | ≥ 135°C |
| Dielectric- factor loss | tgδ (90℃)% ≤ 0.005 |
Product Packaging:
Shipping:
Q: What is the brand name of this Transformer Oil Filtration Machine?
A: The brand name of this Transformer Oil Filtration Machine is HLA.
Q: What is the model number of this Transformer Oil Filtration Machine?
A: The model number of this Transformer Oil Filtration Machine is DVP30-300.
Q: Where is this Transformer Oil Filtration Machine manufactured?
A: This Transformer Oil Filtration Machine is manufactured in Chongqing, China.
Q: What is the input voltage requirement for this Transformer Oil Filtration Machine?
A: The input voltage requirement for this Transformer Oil Filtration Machine is 380V, 50Hz, 3-phase or by customized
Q: What is the flow rate of this Transformer Oil Filtration Machine?
A: The flow rate of this Transformer Oil Filtration Machine is 300 liters per hour.
