    Product Details:

    Place of Origin: Chongqing,China
    Brand Name: HLA
    Certification: CE,ISO9001,ISO14001,BV
    Model Number: DSF200

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiation
    Packaging Details: Wooden case suitable for sea transportation and air transportation
    Delivery Time: 10 days
    Payment Terms: T/T, L/C, Western Union
    Supply Ability: 500 sets/year
    Contact Now
    Detailed Product Description
    Flow Rate: 12000L/hour Filtering Precision: ≤1 Micron
    Water Content: ≤10ppm Gas Content: ≤0.1%
    Temperature Range: 20-80℃ Heated Surface: ≤1.0W/cm2
    Working Pressure: ≤0.4 Mpa Usage: UCO Dehydration,Edulcoration
    Color: As Per Customer's Request Power Supply: By Customized
    Material: Cabon Steel And Stainless Steel Environmental: Friendly

    UCO Purification Cooking Oil Purification Machine Stainless Steel Anti Corrosion



    Filtering cooking oil has many benefits, from extending the life of the oil to increasing the food quality. Our DSF cooking oil purifier can greatly increase the usable life of your cooking oil by removing water, impurities, odor, acidity, color etc, instead of simply replacing the oil.


    This system will give you more use out of your restaurant's cooking oil. It is safer for employees, it lasts longer, and it removes the unsightly waste that normally comes with frying oil.


    DSF cooking oil purifier can save you up to 50% on your oil purchasing, reduce your storage needs, reduce your oil disposal needs, increase the taste and quality of your foods and provide your customers healthier deep fried foods.



    ◇ This plant is composed of two parts, one is the press filter, and the other is the vacuum oil purifier system. The press filter can remove the big or tiny impurities; The precision of purification can reach to 1 Micron. The vacuum system is equipped with filters of three grade (primary filter, mass water separator, and fine filer). All processes is under vacuum condition.

    ◇ The primary filter, which is made of the stainless steel, is anti-rust and anti-corrupt. It mainly removes the residual impurities which escape from the press filter, making sure the treated oil won't have any impurity when it goes into the water separator and vacuum separator.

    ◇ The water separator, which is equipped with a special filter, mainly removes the mass water from the oil. usually the waste cooking oil contains much water and it need to be removed from the oil. After the water separator, the oil just contains the tiny water and soluble water.

    ◇ After the process of the water separator, the oil will goes into the vacuum separator which adopts three-dimensional duplex evaporation and film evaporation. The tiny water, soluble water, acid, alcohol, other volatility liquid and so on can be removed completely and effectively.

    ◇ For the fine filter, which is equips with the stainless steel filter, the purification hole is less than 1 Micro, which can make sure the filtered oil is completely clear without any impurity.

    ◇ It adopts back flushing system, which can clear impurities automatically.

    ◇ We uses stainless steel filter element which is good at anti-corrosion. Especially, the precision of filtering impurities is quite high and the service life is long. Also, it has a large volume for storing the impurities.

    ◇ Its unique degassing and dewatering system adopts the 3D-evaporation technique and thin film evaporation, which can separate the trace water, soluble water and gas from the oil quickly by the multi-level water-oil separation technology.

    ◇ Using the most advanced atomizing separation technology, oil atomization ≤ 50um, multiple opportunities to enhance the gas molecules and water molecules exposed to the vacuum system and extends the flowing distance in the vacuum system to ensure water and gas vaporized sufficient time to complete removal of moisture and gas

    ◇ Advanced vacuum defoaming technology to avoid the oil ejecting and gushing during the process


    Technical specification:

    Model DSF200
    Capacity(L/min) 200
    Working vacuum -0.06~-0.095 Mpa
    Working pressure ≤ 0.4 Mpa
    Temperature range 20-80℃
    Water content ≤10 ppm
    Gas content ≤ 0.1%
    Acid Value ≤0.05 mKOH/g
    Cleanness NAS 6 grade
    Filtering precision ≤1 micron
    Continuous work 100 hr
    No failure running ≥5000 hr
    Power supply 380V, 50HZ, 3PH ( or Customized )
    Working noise 65 dB
    Heating power (kw) 145
    Total power (kw) 157
    Inlet/outlet(mm) 58
    Weight (kg) 1200



    L 1900
    W 1250
    H 1950


    Oil index after treated:

    Item Guarantee indexes
    Moisture content ≤10 PPM
    Demulsification value New oil≤15min, running oil≤30min
    Impurity size ≤1 micron (no free carbon)
    Gas content ≤0.1%
    Clean degree ≤6 Grade (NAS1638)


    Our Services:

    Since the foundation of our company, we have been devoting our efforts to developing better purifiers for energy saving. With the intellectual support form our first-rate oil purification experts and encouraged by the company's modern management mechanism, we have developed twelve series of products, including hundreds of oil purifier models,such as transformer oil purifier,lube oil purifier,turbine oil purifier,cooking oil purifier,diesel oil purifier,engine oil recycling,motor oil purification,fuel oil purifier,centrifugal oil purifier,heavy oil water separator,hydraulic oil purifier etc.


    Our equipment can be applied to many fields, such as electric power, petroleum chemical, metallurgical industry, mining, aviation, shipping railway and so on. We adhere to the tenet of mutual-benefit and win-win business. With the sincere and pragmatic work attitude, we would like to open up a new oil purification are with our customers.
