Black Turbine Oil Purification Machine With Interlocked Protective System

Black Turbine Oil Purification Machine With Interlocked Protective System

  • Black Turbine Oil Purification Machine With Interlocked Protective System
  • Black Turbine Oil Purification Machine With Interlocked Protective System
Black Turbine Oil Purification Machine With Interlocked Protective System
Product Details:
Place of Origin: Chongqing,China
Brand Name: HLA
Certification: ISO9001,CE,ISO14001,BV
Model Number: TVP10
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Wooden case suitable for sea transportation and air transportation
Delivery Time: 10 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 500 sets/year
Contact Now
Detailed Product Description
Flow Rate: 600L/hour Filtering Precision: ≤3 Micron
Water Content: ≤10ppm Gas Content: ≤0.1%
Temperature Range: 0-100℃ Heated Surface: ≤2.0W/cm2
Working Pressure: ≤0.4 Mpa Operation Mode: Automatilc & Manual
Total Power: 27kw Usage: Purify Used Turbine Oil
High Light:

turbine oil purifier

,

turbine oil purification system

Black Turbine Oil Purification Machine With Interlocked Protective System



Application:

Series TVP vacuum oil purifier is special designed for turbine oil, lubricating oil and cooling oil to removing a large amount of moisture and impurity. Such as power plants, power station steam turbine in the process of running, moisture, dust and impurities will be mixed in the turbine oil, will accelerate the oxidation of oil, and changed with foam, fouling and oil sludge, cause the oil emulsified serious, and lead to oil-water separation more difficult, reduce the oil performance of lubrication, speed, cooling etc. Meanwhile caused the metal parts of turbine steam to corrosion, bad for the safe operation of steam turbine. So TVP series machine is the special maintenance equipment for the power plant, power station to clean the used turbine oil.



About TVP10:

This is a vacuum type of our TVP10 model lubricant oil purifier machine with high vacuum pump and oil water separator ,it can treat 10L/minute(600L/hour) lube oil,lubricating oil,hydraulic oil,gear oil,compressor oil, furnace oil,refrigeration oil,vacuum pump oil, bearing oil, metal processing oil, rust-proof oil, oil cylinder oil, heat treatment and heat conduction oil.



This LVP10 automatic vacuum type lube oil purifier machine mostly suitable for shipbuilding, steel work, bridge, car, machinery, railway, petrochemical, metallurgy,oil refineries, hydraulic station etc.



Features:

1. Breaking emulsification thoroughly by means of polymeric material.

2. Dewatering high-effectively with once and for two steps dehydrator method, TVP series can thoroughly remove the liquid water, free water and 80% of dissolved water. It used the coalescence and separation technique and Duplex stereo-evaporation technology which has strong ability to break emulsion and remove water from the oil.

3. With HLA’s distinctive removing impurities technique filtering through double FH trapezoidal network and absorbing by polymeric material, this machine can make the surpass or equal to 200 and make the cleanness not surpass grade 6 (NAS1638). Precise multi-stage filtration system help removes different kinds of impurities.

4. With the trapezoidal, spiral, automatic back flushing system.

5. With the advanced dielectric condensation devices.

6. The machine adopt Carbon fiber infrared heating system which can heating the oil speedy , stable and uniform.

7. Advanced infrared oil level control system and pressure protection device make operation simple and safe.

8. It can purify any kinds of turbine oil used in steam turbine and water turbine online and onsite.

9. Advanced dielectric condensation cooling system helps cool down air and gases from the flash distillation column so as to extend the service life of vacuum pump, avoiding the inconvenience of water cooling.

10. The machine can also be installed with digital flow meter to calculate and record the value of output oil (It is optional).

11. The Automatic oil purifier model is installed with PLC (Programmable logical control system) which can control the equipment automatically to every stage of its process and ensure its process and ensure its safe operation on site and on line without human supervision.

12. The equipment is installed with auto alarming system, it will give out alarm and stop the whole machine when electrical motor is overloaded, vacuum pump and oil pump overloaded, heater overloaded and pressure abnormal.



Technical specification:

Model TVP-10
Capacity(L/min) 10
Working vacuum -0.06~-0.095 Mpa
Working pressure ≤ 0.4 Mpa
Temperature range 0-100℃
Water content ≤10 ppm
Gas content ≤ 0.1%
Demulsifying value ≤15min(GB/F7035)
Cleanness NAS 6 grade
Filtering precision ≤3 micron
Continuous work 100 hr
No failure running ≥5000 hr
Power supply 380V, 50HZ, 3PH ( or Customized )
Working noise 65 dB
Heating power (kw) 24
Total power (kw) 27
Inlet/outlet(mm) 25
Weight (kg) 300

Dimension

(mm)

L 1200
W 600
H 1280



Available Parts for customer option:

1. Fully closed-type for protecting oil purifier machine (weather proof, vacuum proof, Waterproof, dustproof etc.)

2. Mobile trailer with enclosed type can move long distance working in field.

3. Choosing different vacuum pump, oil pump and electric parts(such as SCHNEIDER, SIEMENS, LEYBOLD,ABB etc.)

4. PLC controller for operation fully-automatically and explosion proof materials

5. On-line Moisture detector, flow meter, viscosity tester, acidity tester etc.
